MADE IN JAPAN

Đặc điểm

• It is compact yet high-performance, enabling efficient environmental testing through a network.
• We have achieved the industry's first 5-year warranty.
• With a wide range of functions and options, system upgrades are easy, supporting your testing, research, and experiments.
• We also offer a high-speed temperature change type with a rate of 5°C/minute. (SU-242-5, SH-242-5)

Ứng dụng

• Tests, research, experiments

Thông số chi tiết

• Balanced Temperature and Humidity Control System (BTHC System)
• Safety Devices: Sample power control terminal, over-temperature protection device, temperature upper limit deviation alarm function, absolute temperature and humidity upper and lower limit alarm function, control circuit overcurrent protection, control circuit short circuit protection glass tube fuse
• Power cord length: Approx. 2.5m
• Humidity range: 30-95%RH
• Power supply (V): Single phase 100
• Internal volume (L): 22.5
• Body dimensions (mm) Width: 440
• Body dimensions (mm) Depth: 696
• Body dimensions (mm) Height: 690
• Effective internal dimensions (mm) Width: 300
• Effective internal dimensions (mm) Depth: 250
• Effective internal dimensions (mm) Height: 300
• Operating temperature range (°C): -20 to +150
• Power cord length (m): Approx. 2.5
• Thermostat: Function included

ESPEC SH-222
