MADE IN JAPAN

Đặc điểm

• Because the inner layer is made of tetrafluoroethylene (ETFE) resin, it has excellent solvent and chemical resistance and is resistant to most chemicals.
• It is resistant to crushing, has excellent shape retention when bent, and can also be used for vacuum (suction) applications.

Ứng dụng

• Piping for transporting pharmaceuticals, food, beverages, oil, gasoline, etc.

Thông số chi tiết

• Operating temperature range: -20 to 80°C.
• Complies with the Food Sanitation Law (positive list compliant).
• Color: Transparent. Inner
• Color: Transparent.
• Inner
• diameter (mm): 19. Outer diameter (mm): 26. Total length (m) : 20. Minimum bending radius (mm): 75. Operating pressure (MPa): -0.1 to 0.4. Operating temperature range (°C): -20 to 80. Suitable fluids: Butyl acetate, methyl isobutyl acetate, ethylenediamine.
• diameter (mm): 19. Outer diameter (mm): 26.
• Total length (m)
• : 20. Minimum bending radius (mm): 75.
• Operating pressure (MPa): -0.1 to 0.4.
• Operating temperature range (°C): -20 to 80.
• Suitable fluids: Butyl acetate, methyl isobutyl acetate, ethylenediamine.

HAKKO E-SJSP-19
