MADE IN JAPAN

Đặc điểm

• Because it is a cylindrical furnace, the workpiece can be heated evenly.
• The overheat protection function is included as standard equipment, providing greater peace of mind.
• It is designed to be energy-efficient.
• Its compact size allows you to move it freely around your workspace.
• It can be easily operated using the manufacturer's proprietary temperature controller.

Ứng dụng

• For hardening, tempering, and annealing metals, as well as for melting, firing, sintering, and drying aluminum.

Thông số chi tiết

• Maximum temperature: 1150℃
• Normal operating temperature: 1100℃
• Power: Three-phase 200V 4kW
• Furnace internal dimensions: φ400mm × 400mm
• Load capacity: 10kg or less
• Overheating prevention function standard equipment
• Power cord length: 3m (plug not included)
• Power supply (V): Three-phase 200
• Body dimensions (mm) Width: 620
• Body dimensions (mm) Depth: 620
• Body dimensions (mm) Height: 700
• Effective internal dimensions (mm) Width: 400
• Effective internal dimensions (mm) Depth: 400
• Effective internal dimensions (mm) Height: 370
• Power consumption (kW): 4
• Temperature control method: PID control
• Cord length (m): 3
• Power consumption (W): 4000
• Furnace internal dimensions (mm): φ400 × 400
• Effective internal dimensions (mm) Diameter × Height: 370
• Flow meter, piping not included
• Normal operating temperature range (℃): 1100

HATA LH-TB
