MADE IN JAPAN

Đặc điểm

• Because it is a cylindrical furnace, the workpiece can be heated evenly.
• The overheat protection function is included as standard equipment, providing greater peace of mind.
• Its compact size allows you to move it freely around your workspace.
• It can be easily operated using the manufacturer's proprietary temperature controller.
• It is designed to be energy-efficient.

Ứng dụng

• For hardening, tempering, and annealing metals, as well as for melting, firing, sintering, and drying aluminum.

Thông số chi tiết

• Maximum temperature: 1050℃
• Normal operating temperature: 1000℃
• Power: 100V 1.3Kw
• Furnace internal dimensions: φ200mm × 300mm
• Load capacity: 5kg or less
• Overheating prevention function standard equipment
• Power cord length: 3m (with plug)
• Power supply (V): Single phase 100
• Body dimensions (mm) Width: 355
• Body dimensions (mm) Depth: 355
• Body dimensions (mm) Height: 540
• Effective internal dimensions (mm) Width: 200
• Effective internal dimensions (mm) Depth: 200
• Effective internal dimensions (mm) Height: 275
• Power consumption (kW): 1.3
• Temperature control method: PID control
• Cord length (m): 3
• Power consumption (W): 1300
• Furnace internal dimensions (mm): φ200 × 300
• Effective internal dimensions (mm) Diameter × Height: 275
• Flow meter, piping not included
• Normal operating temperature range (℃): 1000

HATA SL-TB
