MADE IN JAPAN

Đặc điểm

• Heat pump balance control enables energy savings of up to 80% (patented).
• It achieves high-precision handling that is impossible with general air conditioners or conventional heat control systems.
• It Đặc điểm a highly functional and comprehensive design.

Ứng dụng

• To achieve higher temperature and clean environments.

Thông số chi tiết

• Temperature-controlled type
• Power supply (V): Three-phase 200±10% (50/60)
• Air volume (m³/min): 75-80
• Width (mm): Indoor unit 1500 / Outdoor unit 870
• Depth (mm): Indoor unit 600 / Outdoor unit 800
• Height (mm): Indoor unit 1800 / Outdoor unit 1420
• Settable temperature range (°C): 18-30 (circulation type)
• Type: Constant temperature
• Cooling capacity (50/60Hz) (kW): 25.0
• Heating capacity (50/60Hz) (kW): 13.0
• Rated processing air volume (m³/min): 75-80
• Maximum external static pressure (50/60Hz) (Pa): 400
• Power consumption (without auxiliary heater / maximum) (kW): 11/17
• Air volume (m³/min): 80

ORION PAP80B-R
