MADE IN JAPAN

Đặc điểm

• This model is one of the most affordable in the Toyo Connector series.
• [Leak and detachment prevention] This hose fitting prevents production problems such as fluid leaks and hose detachment.
• [Easy Installation] The hexagonal part of the nut is designed to fit JIS wrench size, eliminating the need for special tools and contributing to improved work efficiency.
• [Lightweight and Compact] Compared to the TC3-S, it is lighter and more compact, making it easy to install even in confined spaces.
• [Reusable] For short-term use such as assembly tests and trial runs, the sleeves can be reused, which helps reduce costs.
• (The hose and sleeve can be reused up to three times, provided that each use is within 24 hours at room temperature.)
• ◎There is a product description video. Please take a look.
• If you are looking for a resin (PP) product, please check the "TC2-P model".
• If you are looking for a brass product, please check out "TC3-B type".

Ứng dụng

• Toyox hose-specific fittings
• Fittings for factory equipment piping and various machinery installations

Thông số chi tiết

• Operating pressure and temperature range: Conforms to the applicable hose standard.
• Applicable hose inner diameter (mm): 15.
• Applicable hose outer diameter (mm): 22.
• Thread size: R3/4.
• Applicable fluids: Air, water (industrial water), oil.
• Dimensions L (mm): 47.
• Dimensions φd1 (mm): 13.
• Dimensions HEX1 (mm): 33.
• Dimensions HEX2 (mm): 32.

TOYOX TC2-S15-R3/4
