Đặc điểm

• It has excellent flame retardancy and chemical resistance.

Ứng dụng

• Heat-resistant applications include interlayer insulation and conductor insulation for heaters and transformers.
• Masking during the soldering process of printed circuit boards.

Thông số chi tiết

• Color: Brownish-red
• Width (mm): 10
• Length (m): 33
• Thickness (mm): 0.065
• Tape cutting conditions: Cutter required for cutting
• Adhesive strength (N/10mm): 2.5
• Tensile strength (N/10mm): 35.3
• Compliance standards: UL certified (File No. E50292)
• Dielectric breakdown strength (kV/mm): 5.2
• Core size (mm): 3 inches (76mm)
• Base material thickness (mm): 0.025
• Elongation (%): 50

TRUSCO TPFT-10-33
