Đặc điểm

• Pumping is possible with just 10mm of water below the bottom of the pump, and a minimum water level of 5mm has been achieved for continuous operation.
• This type does not require priming.
• It employs a high-spin impeller made of water-resistant special urethane rubber, which is highly resistant to clogging caused by sand and mud, and boasts approximately three times the abrasion resistance of FCD material.
• Even if the bottom strainer becomes clogged, water can still be drawn in through the side slits thanks to the action of the rubber bellows.
• The bottom section, from the pump casing to the stand, is integrally molded from synthetic rubber. It is suitable for use in FRP tanks and similar applications.
• The pump is designed to remain stable even when turned upside down. Maintenance can be performed on the pump section using only a 13mm box wrench without having to remove the impeller.

Ứng dụng

• For low water level drainage.
• For draining floor water and residual water in general construction work.
• For draining residual water from the bottom of manholes, pits, and water receiving/supply tanks.

Thông số chi tiết

• Non-automatic operation type
• Power cord length: 5m
• Custom-made versions available for different voltages
• Discharge volume (L/min): 120
• Total head (m): 8
• Frequency (Hz): 50
• Bore diameter (mm): 50
• Power supply (V): Single-phase 100
• Current (A): 6.8
• Output (kW): 0.48
• Overall width (mm): 210
• Overall length (mm): 210
• Overall height (mm): 304
• Foreign object passage diameter (mm): 6
• Usable water quality: Cleaning water, floor water, stagnant water
• Power cord length (m): 5

TSURUMI LSR2.4S 50HZ
